LTF QLUX DC LED Boards

QLUX DC LED boards are high quality solid state light emitters and easily customizable for your application. They are optimized solutions for creating a uniform high quality light source. QLUX can be used in a broad range of architectural and general illumination. Each model is carefully created to fit best in its class for a superior lighting experience and high reliability.

Key Features:

  • High lumen output up to +150lm/W
  • High CRI 85+ and 90+ up to 98 CRI
  • Standard and custom form factors
  • ROHS compliant
  • 5 Years or 50,000 hour warranty
50,000 Hour OEM Limited Warranty Badge

NEW! QLUX DC CSP LED Board Series

QLUXS5715W12LED 57mm square 15W 36V DC CSP LED Board

QLUXS 15W 57mm Square CSP LED Board

Model Number: QLUXS5715W12LED9

Wattage: 15W

CRI: 96  R9: 80+

Lumens: 1184 lm

Available CCT: 2700K, 3000K

Download the Spec Sheet (PDF)  >

QLUXS186W3LED 6W 18mm Square 90 CRI 700mA 9V Y19 DC CSP LED Board

QLUXS 6W 18mm Square CSP LED Board

Model Number: QLUXS186W3LED9

Wattage: 6W

CRI: 97  R9: 81

Lumens: 444 lm

Available CCT: 2700K, 3000K

Download the Spec Sheet (PDF)  >

Model Number Product Photo Max. Wattage Typ. Forward Voltage Typ. Forward Current Dimensions Data Sheet
QLUXR895W24LED930K-2 QLUXR895W24LED930K-2 QLUX DC LED Boards 5W 34V 5W 34V 150mA 89mm OD
QLUXR895W24LED930K-2 QLUX DC LED Boards 5W 34V Spec Sheet Download PDF
QLUXR509W30LED9 QLUXR509W30LED9 QLUX DC LED Boards 9W 18V 9W 18V 500mA 50mm OD
QLUXR509W30LED9 QLUX DC LED Boards 9W 18V Spec Sheet Download PDF
QLUXR5010W35LED9 QLUXR5010W35LED9 QLUX DC LED Boards 10W 21V 10W 21V 500mA 50mm OD
QLUXR5010W35LED9 QLUX DC LED Boards 10W 21V Spec Sheet Download PDF
QLUXR7615W48LED QLUXR7615W48LED QLUX DC LED Boards 22W 36V 22W 36V 420mA 76mm (OD) QLUXR7615W48LED QLUX DC LED Boards 22W 36V Spec Sheet Download PDF
QLUXR15230W96LED QLUXR15230W96LED QLUX DC LED Boards 48W 36V 48W 36V 900mA 152mm (OD) QLUXR15230W96LED QLUX DC LED Boards 48W 36V Spec Sheet Download PDF
QLUXR22330W100LED QLUXR22330W100LED QLUX DC LED Boards 50W 30V 50W 30V 1000mA 228mm (OD) QLUXR22330W100LED QLUX DC LED Boards 50W 30V Spec Sheet Download PDF
QLUXL3053.9W28LED QLUXL3053.9W28LED QLUX DC LED Boards 3.9W 24V 3.9W 24V 160mA 305×21mm
QLUXL3053.9W28LED QLUX DC LED Boards 3.9W 24V Spec Sheet Download PDF
QLUXL3058W28LED QLUXL3058W28LED QLUX DC LED Boards 8W 24V 8W 24V 330mA 305×21mm
QLUXL3058W28LED QLUX DC LED Boards 8W 24V Spec Sheet Download PDF
QLUXL55924LED QLUXL55924LED QLUX DC LED Boards 8W 24V 8W 24V 350mA 558.8×25.4mm
QLUXL55924LED QLUX DC LED Boards 8W 24V Spec Sheet Download PDF
QLUXL30512W28LED QLUXL30512W28LED QLUX DC LED Boards 12W 24V 12W 24V 500mA 305×21mm
QLUXL30512W28LED QLUX DC LED Boards 12W 24V Spec Sheet Download PDF
QLUXL15224LED QLUXL15224LED QLUX DC LED BOARDS 15W 30V 12W 36V 200mA 152×12.7mm
QLUXL15224LED QLUX DC LED BOARDS 15W 30V Spec Sheet Download PDF
QLUXL27630LEDRB QLUXL27630LEDRB QLUX DCLED BOARDS 15W 30V 15W 30V 300mA 276×12.7mm
QLUXL27630LEDRB QLUX LED BOARDS 15W 30V Spec Sheet Download PDF
QLUXL29232LED QLUXL29232LED QLUX DC LED BOARDS 16W 24V 16W 24V 400mA 292x10mm
QLUXL29232LED QLUX DC LED BOARDS 16W 24V Spec Sheet Download PDF
QLUXL54532LED QLUXL54532LED QLUX DC LED BOARDS 16W 24V 16W 24V 400mA 545×12.7mm
QLUXL54532LED QLUX LED BOARDS 16W 24V Spec Sheet Download PDF
QLUXL57548LED QLUXL57548LED QLUX DC LED Boards 16.5W 24V 16.5W 24V 700mA 575x25mm
QLUXL57548LED QLUX LED Boards 16.5W 24V Spec Sheet Download PDF
QLUXL8445LED QLUXL8445LED QLUX DC LED Boards 22W 27V 22W 27V 500mA 84x42mm
QLUXL8445LED QLUX DC LED Boards 22W 27V Spec Sheet Download PDF
QLUXL29248LED QLUXL29248LED QLUX DC LED Boards 22W 36V 22W 36V 420mA 292x22mm
QLUXL29248LED QLUX DC LED Boards 22W 36V Spec Sheet Download PDF
QLUXL54364LED QLUXL54364LED QLUX DC LED Boards 32W 24V 32W 24V 800mA 543×25.4mm
QLUXL54364LED QLUX DC LED Boards 32W 24V Spec Sheet Download PDF
QLUXL572108LED QLUXL572108LED QLUX DC LED Boards 34W 17V 34W 17V 1200mA 572X5.8mm
QLUXL572108LED QLUX DC LED Boards 34W 17V Spec Sheet Download PDF
QLUXL55784LED QLUXL55784LED QLUX DC LED Boards 42W 36V 42W 36V 700mA 557x35mm
QLUXL55784LED QLUX DC LED Boards 42W 36V Spec Sheet Download PDF
QLUXL55896LED QLUXL55896LED QLUX DC LED Boards 48W 36V 48W 36V 800mA 558x50mm
QLUXL55896LED QLUX DC LED Boards 48W 36V Spec Sheet Download PDF
QLUXS19530W100LED QLUXS19530W100LED QLUX DC LED Boards 50W 30V 50W 30V 1000mA 195x195mm
QLUXS19530W100LED QLUX DC LED Boards 50W 30V Spec Sheet Download PDF
